No More than what you want, No Less than what you need
1 Scan, 2 Images
One scan with the Smart gives you not just a CT image but also an Auto Pano image. This means, patients who require both images do not need to undergo two X-ray scans. Also CT and Auto Pano images are displayed within the One Viewer feature.
Practical 3 in 1 System
CBCT(with Auto Pano), Panoramic, Cephalometric
SMART Innovation for Low Dose
- 1 Scan, 2 Images
- Low Dose and High Image Quality
SMART Innovation for Accurate Diagnosis
- Anatomical FOV 12x9
Anatomical FOV, 12x9
The innovative FOV of the PaX-i3D Smart provides an arch-shaped volume, which shows a wider view of dentition compared to other devices of the same FOV. Normally, a FOV 10x8.5 image shows tooth #8. However, when the tooth is lying on its side, there is a high possibility that the tooth will be cut out of the image. The "arch-shaped volume" eliminates this possibility and shows the hidden dentition area.
ART-V (Artifact Reduction Technology of VATECH)
ART-V finds out the location of metals when radiation is exposed. And it deletes the metal in projection data artificially and fills that part with the similar values to surrounding area. At the same time, it remembers the original location and status of metals and then it inpaints the area with new value which has no streaks.
Same words, but different meaning
Metal artifact hinders visualization and naturally reduces diagnostic confidence
PROFESSIONAL DIAGNOSTIC VALUE WITH PANORAMIC IMAGES
Smart Plus Provides the most precise and high quality panoramic image. Clear and sharp panoramic image brings you better diagnostics. Enhanced details especially in the anterior and dental roots can be viewed. These consistently high quality images will become the new standard of panoramic imaging.
PROFESSIONAL DIAGNOSTIC VALUE WITH CEPHALOMETRIC IMAGES
Smart Plus provides optimal images with an exclusively designed sensor for cephalometric diagnosis.
Scan type Cephalometric
Scan type cephalometric offers two image sizes, LAT and FULL LAT, you can choose one of them based on the purposes of your diagnostic needs.
LATERAL FULL LATERAL
Provide specialized high quality images to suit Full lateral gives 30% larger images and the occipital orthodontics and maxillofacial surgeries' area of the patient for comprehensive diagnosis (optional).
|Pax-i3D Smart SC||●||●||●|
SPECIFICATIONS (PaX-i3D Smart : PHT-30LFO)
|Function||CT(with Auto Pano) + Pano + Ceph|
|CT - FOV Size(cm)||
10X8.5(Anatomical 12X9 cm) : 5X5 / 10X7 / 10X8.5
8X8 : 8X8
|Voxel Size||0.08mm / 0.2mm / 0.3mm|
|Pano||13.6sec / 7sec [Option with Mageic PAN]|
|Ceph||Scan : 12.9sec|
|Recon Time||CT||Max. 90 sec. (10X8.5 / 0.2 Voxel Basis)|
|Pano||Less than 2 sec|
|Tube Voltage/Current||50-99 kVp / 4 - 16 mA|
